Light Engine-2

1 / 2 / 3

R-SERIES LIGHT ENGINE
Features
  • Durable BLV 150W bulb or 'Osram HQl-R 150W' disch-argelight bublb, which has an average bulb life of over 6,000 active hours.
  • Cold light reflector and UV/thermo Dualpurpose Fiter for minimizing heat and UV light.
  • Thermos switch for extra precaution in case of overheating.

R-150BS
INPUT POWER: AC 120V/60Hz 230V/50Hz
LAMP: /150W USHIO
FUSE: 125V/1A 250V/2A
COLOR WHEEL: SINGLE COLOR SELECTED
SIZE: L220XW210XH95mm
WEIGHT: 4.2kg

　

R-150
IINPUT PROWER: 120V/60HZ 230V/50HZ
LAMP: HQL-R 150W DISCHARGE LAMP
MOTOR: STEPPING MOTOR
COLOR WHEEL: CW-1
SIZE: L260XW340XH150mm
WEIGHT: 9.0kg
FUNCTION:

  • CONTINUE CHANGE COLOR
  • CHANGE COLOR BY STEPPING
  • FIX COLOR
    • R-150 DMX
    INPUT POWER: 120V/60HZ 230V/50HZ
    LAMP: HQI-R 150W DISCHARGE LAMP
    MOTOR: STEPPING MOTOR
    COLOR WHEEL: CW-1
    SIZE: L260XW340XH140mm
    WEIGHT:9.0kg
    		　

    		R-150 DMX M/S LIGHT ENGINE
    TECHNICAL DATA
    POWER: AC 120V/60Hz 230V/50Hz
    LAMP:HQL-R 150W/NDL 6000HRS OSRAM
    COLOR: Red, Yellow, Blue, Green, Pink, Purple, Light BLUE And White
    (WITH COLOR WHEEL CW-1)
    MOTOR: Stepping Motor
    SIZE:L270XW340XH150mm
    		CONTROL SYSTEM:
  • DMX 512 Signal
  • Fully Programmable Via DMX 512
  • Sound Activated
  • Stand Alone Mode
  • Master Slave Mode
  • Efficient Cooling Fan
  • Overheating Protected
    WEIGHT:9.5kg

    • R-400 DMX M/S LIGHT ENGINE
    TECHNICAL DATA
    POWER: AC 230V 50HZ
    LAMP: HTI 403W/24 750HRS OSRAM
    COLOR: Red, Yellow, Blue, Green, Pink, Purple, Light BLUE And White
    (WITH COLOR WHEEL CW-1)
    MOTOR: Micro-Stepping Motor
    COOL: DC FAN
    SIZE:L450XW300XH200mm
    		C
    ONTROL SYSTEM:
  • DMX 512 Signal
  • Fully Programmable Via DMX 512
  • Sound Activated
  • Stand Alone Mode
  • Master Slave Mode
  • Efficient Cooling Fan
  • Overheating Protected
  • WEIGHT:11kg

    		• SRC-144 DMX DISTRIBUTOR
    FUNCTIONS
    54 channels DMX control
    9 PROGRAMS
    INPUT POWER : AC 120V/60Hz, 230V/50Hz   CONTROLLER INPUT DC 9V-12V，500mA
     size: L450XW300XH200mm


    		1 / 2 / 3
